Large Scale Calorimeter, Industrial & real scale calorimeter : Avg, max 10 MW/m2, ISO 9705, 1993, PrEN 13823, IEC 60332-3
The principle of Large Scale Calorimeter test is same as that of Cone Calorimeter.
While the Cone Calorimeter measures up to 0.5 MW, LSC measures 1~ 10 MW quantitative heat release rate(HRR).
Also, while the Cone Calorimeter collects certain test materials(100 ¡¿ 100 mm) for test, FESTEC's Large Scale Calorimeter measures real fire (for example, fire from a warehouse, the whole office, furniture and a car)  likely to occur in the actual situation. For these reasons, this equipment is called Large Scale Calorimeter or Industry Calorimeter.
This test is able to measure the full scale fire experiment such as warehouse, commodity, furniture, car and so no.


ISO 9705, 1993 : Room Corner Tests
Fire Tests - Full scale room tests for surface products

PrEN 13823 : The S.B.I
Reaction to fire tests for building products excluding floorings exposed to thermal attack by a single burning item.

IEC 60332-3 : Cable Testing rig
Ignitability and burning behaviors of materials and products
¨ç LSC 2005 Detector (Flange type)
¨è ¡®+¡¯ type Sampling Gas Probe
¨é Soot mass Sampling Probe
¨ê Shielded Thermocouple
¨ë Bi-directional Velocity Probe and DPT
¨ì Smoke Detection System by Laser
¨í Gas Analysis System (Oxygen, Carbon mono and dioxide)
¨î Data Acquisition System by 'NI' Field Pointer
¨ï Main Controller System (Included Safty cut off)
¨ç Exhaust duct flow rate, Unit: l/s, g/s
¨è C factor, Unit:1/kg․m․K
¨é Extinguishment time, Unit: s
¨ê Total oxygen consumption, Unit: g
¨ë Total Smoke Release, Unit: m/m2
¨ì Mass loss and Mass loss rate, Unit: g, g/s
¨í Heat release rate, Unit: MJ/kg, kw/m2
¨î Effective heat of combustion, Unit: MJ/kg
¨ï Carbon monoxide yield, Unit: kg/kg
¨ð Carbon dioxide yield, Unit: kg/kg
